R134a (1,1,1,2-Tetrafluoroethane, HFC134a, Norflurane) CAS:811-97-2

R134a

R134a (1,1,1,2-Tetrafluoroethane), R-134a, Genetron 134a, Suva 134a, HFC-134a, HFC134a, Dymel 134a or Norflurane, is a haloalkane refrigerant with thermodynamic properties similar to R-12 (dichlorodifluoromethane), but with less ozone depletion potential.

Uses

R134a is an inert gas used primarily as a "high-temperature" refrigerant for domestic refrigeration and automobile air conditioners. These devices began using R134a in the early 1990s as a replacement for the more environmentally harmful R-12, and retrofit kits are available to convert units that were originally R-12-equipped. Other uses include plastic foam blowing, as a cleaning solvent, a propellant for the delivery of pharmaceuticals (e.g. bronchodilators), wine cork removers, gas dusters, and in air driers for removing the moisture from compressed air. R134a has also been used to cool computers in some overclocking attempts. It is also commonly used as a propellant for airsoft airguns.
R134a is also being considered as an organic solvent suitable for extraction of flavor and fragrance compounds, as a possible alternative to other organic solvents and supercritical carbon dioxide. It can also be used as a solvent in organic chemistry, both in liquid and supercritical fluid. It is used in the resistive plate chamber particle detectors in the Large Hadron Collider. It is also used for other types of particle detectors, e.g. some cryogenic particle detectors. It can be used as an alternative to sulfur hexafluoride in magnesium smelting as a shielding gas.
R134a is also being considered as an alternative to sulfur hexafluoride as a dielectric gas. Its arc-quenching properties are poor, but its dielectric properties are fairly good.
An additional use of R134a is as a propellant. It is used in this way mainly for gas-powered airsoft guns. The gas is often mixed with a silicon-based lubricant to assist with maintaining functionality of the airsoft gun.

Package & Transport

Package Type: Disposable Cylinder; Returnable Tank, ISOTANK
Package Size: 13.6KG / 30LB; 1000KG; 17 T
UN Number: 3159
Hazard Class: 2.2

Notice

1. Store in a clean, dry place. Don't heat ≥ 52 ℃ (126 F).
2. Cylinders should be stored upright and firmly secured to prevent falling or being knocked over. Valve protection caps and valve cutlet threaded plugs must remain in place unless container is secured with valve outlet piped to use point. Do not drag, slide or roll cylinders.
3. Separate full containers from empty containers.
4. Avoid area where salt or other corrosive materials are present.

5.Avoid excessive inventory and storage time.

R134a


Molecular formula	CH₂FCF₃
Molar mass	102.03 g/mol

IUPAC Name

1,1,1,2-Tetrafluoroethane

Identifiers

CAS number	811-97-2
EC number	212-377-0
ChemSpider	12577
RTECS number	KI8842500
UNII	DH9E53K1Y8
KEGG	D05208
PubChem	13192
Jmol-3D images	Image 1

SMILES[show]

InChI[show]

Properties

Appearance	Colorless gas
Density	1.2076 g/cm³ (25 ℃)
Melting point	-103.3℃ (169.85 K)
Boiling point	-26.3℃ (246.85 K)
Vapour pressure	4730 mmHg
Solubility in water	0.15 wt%

MSDS	R134a_MSDS.pdf
R-phrases	R10, R20/21/22, R36/38, R62
S-phrases	S2, S23, S24/25, S51
Main hazards	Asphyxiant
NFPA 704
Flash point	250℃ (482 ℉)

Spectral data	UV, IR, NMR, MS
TDS	R134a_TDS.pdf
Others Data	Analysis_report; Toxic_report; Etoxic_report; SGS_report, etc.
